（项目简介）

About the Program

本项目针对越南森林可燃物载量监测和经营成本高，森林可燃物载量监测装备、技术和方法亟需更新，森林可燃物载量快速精准监测和评估能力提高等问题，向越南林业大学提供森林可燃物载量数字化监测与智能化经营技术（包括：基于地面测树装备的立木可燃物载量建模数据采集方法和建模技术、森林可燃物载量智能化经营管理技术），以及相应技术指导。乙方向甲方提供该套技术推广试验基地，以实际行动积极推动中国与越南农林业交流与合作。

This project addresses issues such as the high cost of monitoring forest fuel load and management in Vietnam, the urgent need to update monitoring equipment, technologies, and methods for forest fuel load, and the improvement of capabilities for rapid and accurate monitoring and assessment of forest fuel load. It provides the Vietnam University of Forestry with digital monitoring and intelligent management technologies for forest fuel load (including: data collection methods and modeling techniques for standing tree fuel load based on ground-based tree measurement equipment, as well as intelligent management technologies for forest fuel load), along with corresponding technical guidance. Party B provides Party A with a pilot base for the promotion of this set of technologies, actively promoting agricultural and forestry exchanges and cooperation between China and Vietnam through practical actions.

（示范基地建设及成效：仪器产品+基地示范+提速增效）

Outcomes: varieties

(Equipment + Demonstration Bases + Enhanced Efficiency & Yield )

与越南林业大学合作，建立森林可燃物载量立体化监测与智能化经营实验基地，开展基于地面数字化测树装备的立木可燃物载量数据采集方法和建模技术示范工作。在实验基地内，利用电子罗盘仪进行标准地周界测量确定测量空间范围（面积为1亩，25.82*25.82米），在标准地范围内开展样木胸径、树高、相对位置等测树因子的测量。利用电子测径仪测量标准地内样木的胸径，利用伸缩式测高杆和可穿戴式测高帽测量样木的树高和冠幅。通过“林木采集管理平台app”，将所采集的数据全部无线传输至手机，用于构建蓄积量与可燃物载量互推模型，计算单木和标准地尺度的森林可燃物载量。开展森林可燃物载量结构化智能化经营管理技术示范工作。利用Q值等方法研究不同林分断面积水平的直径和树高结构，利用O-ring和角尺度等方法研究既定立地条件下的林木空间格局，基于混角度和多样性混交度计算树种空间隔离度，拟基于Hegyi、Bitterlich和Gadow等方法计算林木间竞争强度。在此基础上，利用“便携式数字化测树仪数据管理系统V1.0”，对“林木采集管理平台app”采集到的上述结构化经营指标数据进行计算和分析，直接指示经营者需要抚育和采伐的林木，实现森林可燃物的精细化经营。申请专利13项，包括4项发明专利，9项实用新型专利，并获得了11个相关软件著作权。出版了1部专著，发表了30篇学术论文。

In collaboration with Vietnam University of Forestry, a comprehensive monitoring and intelligent management experimental base for forest fuel load was established to demonstrate data collection methods and modeling techniques for standing tree fuel load using ground-based digital tree measurement equipment. Within the experimental base, an electronic compass was used to measure the perimeter of sample plots to define the spatial scope (each covering 1 mu, i.e., 25.82 × 25.82 meters). Within these plots, tree factors such as diameter at breast height (DBH), tree height, and relative position were measured. An electronic caliper was employed to measure the DBH of sample trees, while telescopic height poles and wearable height-measuring caps were used to determine tree height and crown width. The collected data were wirelessly transmitted via the "Tree Data Collection and Management Platform App" to mobile devices for building mutual conversion models between stand volume and fuel load, enabling the calculation of forest fuel load at both individual tree and plot scales.Demonstrations of structured and intelligent management technologies for forest fuel load were also conducted. Methods such as the Q-value were used to analyze the diameter and height structures under different stand basal area conditions, while O-ring and uniform angle index methods were applied to study spatial patterns of trees under specific site conditions. Spatial species segregation was calculated based on mingling and diversity indices, and competition intensity among trees was assessed using methods such as those by Hegyi, Bitterlich, and Gadow. Based on these analyses, the "Portable Digital Tree Measurement Data Management System V1.0" was used to compute and analyze the structured management indicators collected by the app, directly guiding managers in identifying trees requiring thinning or harvesting, thereby achieving precision management of forest fuels. A total of 13 patents were applied for, including 4 invention patents and 9 utility model patents, along with 11 software copyrights. One monograph was published, and 30 academic papers were issued.

图1 基于地面测树装备的立木可燃物载量建模数据采集方法和建模技术示范

Figure 1. Demonstration of Data Collection Methods and Modeling Techniques for Standing Tree Fuel Load Based on Ground-Based Tree Measurement Equipment

图2 与越南林业大学共同参加首届澜湄流域林业大学董事长论坛

Figure 2. Participating in the First Lancang-Mekong Region Forestry University Presidents' Forum together with Vietnam National University of Forestry.
